Dimensions

Overall Length: 240 cm
Overall Width: 119 cm
Overall Height (no canopy): 116 cm
Overall Height (with canopy): 174 cm
Wheel Base: 167 cm
Front Wheel Track: 90 cm
Rear Wheel Track: 97 cm
Ground Clearance (at differential): 11 cm

Power

Power Source: 48 Volts DC
Motor Type: 48 Volt AC
Electric System: 48 Volt
Battery (qty/type): 1 Samsung Lithium Ion 60 Amp Maintenance Free Battery Pack ( Including Battery Management System)
Key or Pedal Start: Pedal Start
Battery Charger: Lithium World Charger 48VDC
Speed Controller: 235 Amp AC Controller
Drive Train: Motor Shaft Direct Drive
Transaxle: Limited Slip Differential
Gear Selection: Forward-Neutral-Reverse Integrated into Key Switch
Rear Axle Ratio: 16.99:1


Performance

Seating Capacity: 2 Person
Dry Weight (without battery): 275 Kg
Curb Weight: 298 Kg
Vehicle Load Capacity: 360 Kg
Outside Clearance Circle: 5.8 m
Intersecting Aisle Clearance: N/A
Speed (level ground): 13 - 24 kph ± 0.8 kph ( Programmable)
Towing Capacity: 3 E-Z-GO Golf Cars with Approved permanent tow bar

Steering & Suspension

Steering: Double-ended Rack and Pinion
Front Suspension: Independent A-arm Coil over Shock
Rear Suspension:  Mono Leaf Springs with hydraulic Shocks
Service Brake: Induction Motor
Parking Brake: Automatic Electro Magnetic
Tyres: Turf Tyres 18 x 8.5 - 8 (4 Ply Rated)

Body & Chassis

Frame: Welded steel with powder coat protection
Front Body & Finish: Injection Moulded, TPO
Rear Body & Finish: Injection Moulded, TPO
Standard Colour: Forest Green
Standard Colour: Almond, Black, Burgundy, Electric Blue, Flame Red, Inferno Red, Ivory, Metallic Charcoal, Orange, Patriot Blue, Platinum, White
Standard Seat Colour: Stone Beige
Optional Seat Colours: Black or Oyster
Pinstriping Colours: Pewter, White, Black, Gold
